Dycon D1520-A 12V 0.5A Power Supply (A Box Housing)

The Dycon D1520-A is a 12V 0.5A power supply unit for use with EN50131 / PD6662 security grade 2 intrusion systems.

The Dycon D1520-A is an EN-Compliant, switched-mode power supplies which satisfies the requirements of EN50131-1 and PD6662 to Security Grade 2. This unit has two voltage free outputs and LEDs are provided to monitor for External Power Supply (EPS) faults and for Auxiliary Power Supply (APS) Faults. The maximum current available from the ‘Power Output’ terminals depends on the type of power supply and the batteries connected.  All batteries are monitored for low-voltage, disconnection and load test and, if more than one battery is fitted, they are monitored individually. The batteries and electronics protected against reverse-polarity battery connection by self-resetting electronic fuses and are also protected against deep discharge which will activate if the voltage drops below 10.5Vdc.

Dycon D1520-A 12V 0.5A Power Supply Unit Dimensions

• 235 x 170 x 85mm
